Four HDMI™ 2.0 output card for LivePremier series
Four HDMI™ 2.0 output card for LivePremier series
![[Four HDMI 2.0 output card for LivePremier™ series]](https://cdn.prod.website-files.com/6540cb540116ce87ec8b62fe/65d708438e473efda9b39a72_banner-22614.avif)
The Analog Way ACC-AQL-OUT-HDMI is a field swappable output card with four HDMI™ 2.0 ports and designed to work with any LivePremier live presentation switcher. Each output port supports resolutions up to 4K60 8 bits 4:4:4 or 4K60 12 bits 4:2:2 or 4K30 12 bits 4:4:4. It can also drive custom output formats such as 8192×1080@60Hz. The card supports up to 8 embedded audio channels per output and features advanced HDCP 1.4 and 2.2 handshake as well as HDR compatibility.
Extremely
USer-Friendly
The CorePlay RCS software provides an intuitive and powerful user interface to configure and control Analog Way CorePlay products. CorePlay Solo offers a REST API over Ethernet for easy integration with third-party control systems. It is also compatible with remote control solutions such as Stream Deck Companion, and natively supports Stream Deck directly connected to the unit. Designed for efficient operation in both standalone and networked environments, CorePlay RCS enables flexible and responsive control across a wide range of applications.
Button TextTHE PERFECT COMPANION FOR PRESENTATION SWITCHERS
4K@60Hz 10-bit output and high playback performance make CorePlay Solo a reliable and versatile video playback solution for live events. System performance is predictable and well documented, making it easy for operators to work with and communicate media specifications.
Playback quality is consistent, with direct support for most common media formats, and preview operations do not disrupt program outputs.
Built for live events and rental staging applications
It’s the small details in CorePlay that make life easier in live events and rental staging applications. With a complete hardware solution, there’s no risk of operating system updates disrupting a show — Analog Way manages the platform, so CorePlay will just work.
Turnaround time in the shop is minimised with fast, simple and secure procedures to reset units to factory defaults and optionally wipe media storage. The integrated 1TB SSD provides fast and reliable local media storage, supporting efficient content deployment between shows. This helps prevent content from one customer being carried over to the next.
Rock-solid reliability
CorePlay Solo is designed to deliver a reliable hardware platform for video playback in demanding environments. It is specifically engineered to withstand live event conditions while ensuring long-term durability for fixed installations. Powered by a Linux engine known for its stability and reliability, CorePlay Solo delivers consistent performance, even in the toughest conditions.
Button Text
Key Features
- Four HDMI™ 2.0 output ports
- Field swappable card (not hot swappable)
- True 4K60 4:4:4 performance on every output port
- Supports 4K60 output as single, double or quad ports
- Each port features screw-in secure locking to prevent cable strain and loose connection
- Connector status LEDs for easy troubleshooting
- HDR compliant with HDR10 and HLG
- High Frame Rate up to 144Hz
- Supports up to 8 embedded audio channels per output (PCM)
- EDID management
- Compliant with HDCP 1.4 and HDCP 2.2
Software and docs
