The Pulse 4K is a powerful 4K60 multi-layer video mixer and seamless presentation switcher, with ten inputs, two PGM outputs and one dedicated Multiviewer.

Tech Spec
10
Inputs
2
PGM Outputs
4K60
4:4:4 10-bit
1
Multiviewer
HDR
and 3D LUT
Up to 4
4K Layers
HDMI
2.0
DP
1.2
12G
SDI
2
Rack Units
IP
Streaming
PLS-4K
[Pulse 4K] Front View
[Pulse 4K] Back View

The Pulse 4K is a powerful 4K60 multi-layer video mixer and seamless presentation switcher, with ten inputs, two PGM outputs and one dedicated Multiviewer.

Pulse 4K
Key Features
Main Accessories
Customer Stories
Downloads
Videos
Related Products
GET IN TOUCH
Key Features

Extremely
USer-Friendly

The CorePlay RCS software is an intuitive, elegant, and powerful user interface to configure and control the Analog Way CorePlay products. CorePlay Solo offers IP (Ethernet) based API which enable easy integration with any third-party control systems. CorePlay Solo is also compatible with various remote control software such as Stream Deck Companion. CorePlay Solo natively supports Stream Deck directly connected to the unit.

Button Text
Key Features

Perfect companion to Presentation Switchers

4K@60Hz 10-bit output and high playback performance make CorePlay Solo a powerful and versatile video playback solution for live events. System performance is predictable and well documented, so it will be easy for operator to communicate on the media specifications.

Playback quality will be optimal, with direct support for most common media formats and preview operations will not disrupt the program outputs.

Button Text
Key Features

Built for live events and rental staging applications

It’s the small things in CorePlay that make life easy in live events and rental applications. With a full hardware solution, you won’t need to worry about surprise operating system updates breaking the show – Analog Way will handle all the details, CorePlay will just work.

Turnaround time in the shop will be minimized by having fast, easy and safe procedure to reset the units to factory defaults and to optionally wipe the media storage. This prevents accidents with medias leaking from one customer to another customer.

Button Text
Key Features

Rock-solid reliability

CorePlay Solo is designed to offer a robust and reliable hardware platform that you can rely on for all of your video playback needs. It is specifically engineered to survive tough live event environments while ensuring long-term durability for fixed installations. Powered by a Linux engine, renowned for its exceptional reliability and stability, CorePlay Solo delivers optimal performance, even in the toughest conditions.

Button Text
overview

Collapse All
Expand All
Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.
2 Operating Modes

Mixer Mode

  • 1 PGM output up to 4K60, with
    • 1 live background
    • 2 resizable mixing 4K layers (or 4 split layers)
    • 1 foreground 4K image layer
  • 1 AUX output up to 1080p60
    • can downscale and display any input or the PGM output

Matrix Mode

  • 2 independant PGM outputs up to 4K60, with, per output
    • 1 live background
    • 1 resizable mixing 4K layers (or 2 split layers)
    • 1 foreground 4K image layer

10 Seamless Inputs
  • 4x HDMI 2.0 - up to 4K60 8-bit 4:4:4 or 4K60 12-bit 4:2:2
  • 2x DisplayPort 1.2 - up to 4K60 10-bit 4:4:4 or 4K60 12-bit 4:2:2
  • 2x 12G/6G/3G-SDI (level A & B) - up to 4K60 10-bit 4:2:2
  • 2x HDMI 1.4 or 3G-SDI (user selectable input plug) - up to 2K60 10-bit 4:4:4 (HDMI) or 2K60 10-bit 4:2:2 (SDI)
  • Support custom input formats up to 4096 width
2 Active Outputs
  • 2x HDMI 2.0 connectors + 2x mirrored 12G/6G/3G-SDI (level A & B) connectors
    • up to 4K60 8-bit 4:4:4 or 4K60 12-bit 4:2:2 (HDMI)
    • up to 4K60 10-bit 4:2:2 (SDI)

  • Support custom output formats up to 4096 width
  • 2 modes available: Matrix (2 independent PGM) or Switcher (1 PGM + 1 AUX)
1 Dedicated Multiviewer Output
  • 1x HDMI 1.4 + 1x mirrored 3G-SDI
  • Resolution up to 2560x1600@60 8-bit 4:2:2
  • 17 resizable widgets - customizable layouts (20 memories)
  • Monitor the Program, Preview and auxiliary screens and all the inputs
  • Built-in clocks, countdown and timers
Multiviewer
Livestreaming
  • RTMP-based Livestreaming of any input or output (including Multiviewer)
  • Compatible with all major Web platform such as Youtube, Facebook, Twitch.tv
  • Streaming to a private network to feed local clients, like OBS software
  • Encoding at up to 1080p30 in H.264 for the video and AAC for the audio
  • Predefined Video Quality sets or Custom bitrate for dedicated application
  • Management of the personal credentials for web services (URL and Private Key)
Ultra-low Latency 4K60 Processing
  • Based on Analog Way exclusive 5th generation scaling engine
  • Ultra-low latency (16msec @60Hz)
  • BT.601; BT.709; BT.2020 color spaces support
  • Split layers mode: double the live layer count (no crossfade effect)
  • Advanced EDID management
  • Area of Interest and advanced output/screen test patterns
  • Compliant with HDR10 and HLG - Built-in SDR/HDR converters
  • Colorspace conversion & color corrections based on 3D LUTs
  • Compatible with HDCP 1.4 and HDCP 2.2
Advanced Audio Processing
  • De-embed/embed audio channels on all inputs/outputs (PCM):
    • 8 channels per HDMI 2.0, 12G-SDI or DisplayPort 1.2 input
    • 4 channels per 3G-SDI input and 2 channels per HDMI 1.4 input
    • 8 channels per active output
  • Level control, Mute, Balance, Delay, 1kHz Sinus Pattern features
  • 1 VU meter display of a selected input on the multiviewer
  • Fixed or dynamic routing (breakaway or top layer)
  • Optional Analog and Dante™ audio networking card:
    • 2 analog stereo mini jack line in and line out 1/8’’ (3.5 mm)
    • 32x32 Dante™ audio channels @48kHz
    • Dual redundancy Ethernet ports - AES67 support
8 Concurrent 4K Still Images
  • 4x 4K concurrent still images for the foreground layer
  • 4x 4K concurrent still images for the background
  • Alpha-channel support
  • Still image library with 50 memories
  • Multi-file download/upload via Web RCS - capture from live inputs

Advanced Video Effect
  • True A/B mix effect
  • Layer border effects and colors with separate shadow
  • Multiple transition effects
  • Luma and Chroma Keying
  • Cut and Fill at input level
  • Layer effects: H/V Flip, Transparency…
  • Color effects: B&W, Negative, Sepia and Solarize

Flexible Control Option
  • Full-featured Front Panel with 480x272 color LCD screen
  • Web RCS: on-board intuitive web-based user interface
  • Built-in SMNPv2-MIB
  • Shot Box2 / Control Box3: Cost effective control solutions
  • RC400T: Ergonomic event controller
  • Compatible with SKARHOOJ Air fly Pro controller
  • Compatible with Companion and Universe control solutions
  • Simple REST API (HTTP) and advanced JSON TCP protocol
  • Creston drivers & AW VideoCompositor (Premium Creston GUI)
Other Features
  • Live monitoring of inputs & PGM on the color TFT LCD display
  • 200 user definable screen memories and 50 master memories
  • Innovative ‘Quick Preset’ feature
  • Dedicated BNC with loop for Genlock, Blackburst and tri-level sync
  • I/O connector status LEDs for easy troubleshooting
  • USB host type A: firmware update, configuration import/export...
  • Fully functional simulator for offline configuration & practice
  • Gigabit Ethernet via Neutrik RJ45
  • Support of TSL protocol
want to dive deeper
Download Datasheet
No items found.
Customer stories
Customer stories
Customer stories
Customer stories
No items found.

Key Features

  • 4K60 multi-layer seamless presentation switcher
  • 10 seamless inputs including 8x 4K60 and 2x 2K60 inputs
  • Two 4K60 PGM outputs with mirrored 12G-SDI and HDMI 2.0 plugs
  • 2 modes: Matrix (2 independent PGM) or Switcher (1 PGM + 1 AUX)
  • Live or still background
  • Up to four 4K split layers (or two 4K mixing layers)
  • Dedicated multiviewer with resizable widgets (PGM, PRW and inputs)
  • Real-time 10-bit 4:4:4 video processing compliant with HDR10 & HLG
  • IP Streaming of any Input or Output based on RTMP
  • Advanced audio processing and dynamic routing
  • Optional analog and Dante™ audio networking card (32x32 channels)
  • Compact 2RU rugged chassis
