ST 2110 input card for LivePremier series
ST 2110 input card for LivePremier series
The ACC-AQL-IN-2110 card is a high-performance SMTPE 2110 input card, designed to work with any LivePremier live presentation switcher. Equipped with 2x 25GbE primary and 2x 25GbE secondary SFP28 ports to be used directly with 25GbE switches and routers, it can de-encapsulate up to 4x 2160p60 or 8x 1080p60 streams from uncompressed ST 2110-20 IP networks.
The ACC-AQL-IN-2110 card is a high-performance SMTPE 2110 input card, designed to work with any LivePremier live presentation switcher. Equipped with 2x 25GbE primary and 2x 25GbE secondary SFP28 ports to be used directly with 25GbE switches and routers, it can de-encapsulate up to 4x 2160p60 or 8x 1080p60 streams from uncompressed ST 2110-20 IP networks.
Extremely
USer-Friendly
The CorePlay RCS software is an intuitive, elegant, and powerful user interface to configure and control the Analog Way CorePlay products. CorePlay Solo offers IP (Ethernet) based API which enable easy integration with any third-party control systems. CorePlay Solo is also compatible with various remote control software such as Stream Deck Companion. CorePlay Solo natively supports Stream Deck directly connected to the unit.
Button TextPerfect companion to Presentation Switchers
4K@60Hz 10-bit output and high playback performance make CorePlay Solo a powerful and versatile video playback solution for live events. System performance is predictable and well documented, so it will be easy for operator to communicate on the media specifications.
Playback quality will be optimal, with direct support for most common media formats and preview operations will not disrupt the program outputs.
Built for live events and rental staging applications
It’s the small things in CorePlay that make life easy in live events and rental applications. With a full hardware solution, you won’t need to worry about surprise operating system updates breaking the show – Analog Way will handle all the details, CorePlay will just work.
Turnaround time in the shop will be minimized by having fast, easy and safe procedure to reset the units to factory defaults and to optionally wipe the media storage. This prevents accidents with medias leaking from one customer to another customer.
Rock-solid reliability
CorePlay Solo is designed to offer a robust and reliable hardware platform that you can rely on for all of your video playback needs. It is specifically engineered to survive tough live event environments while ensuring long-term durability for fixed installations. Powered by a Linux engine, renowned for its exceptional reliability and stability, CorePlay Solo delivers optimal performance, even in the toughest conditions.
Button Text
Key Features
- Four SFP28 input ports (2x primaries, 2x secondaries) - Up to 25 Gbps bandwidth per port
- Support of ST 2110-20 uncompressed active video over managed IP network
- Support of up to four 4K60 or eight 2K60 10-bit 4:2:2 input streams
- Support of PTP synchronization requiring external PTP grandmaster
- Support of NMOS IS-04 for discovery and registration
- Support of NMOS IS-05 for device connection management
- Easy connection configuration based on SDP file
- Support of up to 8 audio channels per UHD/4K video stream or up to 4 audio channels per FHD/2K video stream (in a next SW release)
- Supports BT.709 and BT.2020 color spaces
